    6.6m Tower Steel Crawler Water Well Drilling Rig 280 300 350m

    Ask Lasest Price
    Brand Name : Aoxing
    Model Number : JDL-350
    Certification : ISO9001
    Supply Ability : 30 Sets/Month
    • Product Details
    • Company Profile

    6.6m Tower Steel Crawler Water Well Drilling Rig 280 300 350m

    280 300 350m 6.6m Tower Steel Crawler Water Well Drilling Rig/Deep Water Well Drilling Machine/Water Well Drilling Rig


    Product Description


    Rotary full hydraulic controlled water well drilling rigs are multifunctional, it can be used with air compressor, mud pump. The portable drilling rigs are not only designed for water, they can also be used in all conditions based on pore-forming purpose. This series of water well drilling machine has the characteristics of standardized configuration, compact and reasonable structure, fast drilling speed, economical and durable, low failure rate, etc. It has been recognized by the market once it is launched, and has been widely used in mining engineering construction, civil drilling, geothermal drilling and other fields. They are widely used in industrial and agriculture water project, testing well and other exploration borehole. In particular, drilling hole for geothermal heating, it can also meet the engineering basis for reinforcement, loose gravel drilling rock formation connected with a variety of engineering. Our drilling rigs are more efficiency and with low failure rate, more economic and durable, and with a high comprehensive cost performance.


    Product Parameters:

    Factory direct sales of various water well drilling rigs
    Model
    JDL280
    JDL300
    JDL350
    JDL450
    JDL200
    The weight(T)
    7.6
    7.2
    8.6
    9.4
    5
    Drill pipe diameter(mm)
    76/89
    76/89/102
    89/102
    89/102
    76/89
    The hole diameter(mm)
    140-305
    140-325
    140-325
    140-350
    140-254
    Drill pipe lenght(m)
    1.5m/2.0m/3.0m
    1.5m/2.0m/3.0m
    1.5m/2.0m/3.0m/6.0m
    1.5/2.0/3.0/6.0m
    1.5/2.0/3.0m
    Drilling depth(m)
    280m
    300m
    350m
    450m
    200m
    Rig lifting force(T)
    17
    18
    22
    25
    13
    One-tine advance length(m)
    6.6
    3.3/4.8
    6.6
    6.6
    3.3
    Equipped capacitor(kw)
    74
    85
    92
    103
    65
    Hoisting force of winch(T)
    2
    2
    2
    2
    1.5
    Swing torque(N.m)
    4500-6000
    5700-7500
    6200-8500
    7000-9500
    3400-4700
    Dimension(mm)
    5900*1850*2360
    4100*2000*2500
    6000*2000*2550
    5950*2100*2600
    3950*1750*22
    50
    Swing speed(rpm)
    40-70
    40-70
    66-135
    50-135
    45-70
    The penetration effciency(m/h)
    15-35
    15-35
    15-35
    15-35
    10-35
    Rapid rise speed(m/min)
    25
    22
    18
    20
    30
    Walking speed(km/h)
    2.5
    2.5
    2.5
    2.5
    2.5
    Fast feeding speed(m/min)
    30
    40
    33
    40
    60
