    XY-2 Hydraulic Core Drilling Machine/Mine Exploration, Geological Core Sampling

    Ask Lasest Price
    Brand Name : Aoxing
    Model Number : XY-2Type
    Certification : ISO9001
    Payment Terms : T/T
    Supply Ability : 50 Sets/Month
    • Product Details
    • Company Profile

    XY-2 Hydraulic Core Drilling Machine/Mine Exploration, Geological Core Sampling


    • XY-2 Hydraulic Core Drilling Rig

    1. Scope of application of XY-2 hydraulic core drilling rig

    General geological survey exploration, road and high-rise building foundation exploration, as well as various concrete structure inspection holes, river embankments, subgrade grouting hole drilling and direct grouting, civil water wells, etc.

    2. Main features of XY-2 hydraulic core drilling rig

    (1)The drilling rig adopts an automobile gearbox assembly with multiple speed stages and a reasonable speed adjustment range;

    (2)With large torque and strong bearing capacity, it can realize remote control and speed change, and the operation is centralized and convenient;

    (3)The drilling rig has high power and 2 reverse speeds, which is convenient for handling accidents;

    (4)With a normally closed hydraulic chuck, it is convenient and flexible to operate;

    (5)The vertical shaft through hole has a large diameter, which can be replaced with a large hexagonal active drill rod;

    3. Technical parameters of XY-2 hydraulic core drilling rig

    ModelXY-2
    Drilling depth300m
    Drilling diameter300-75mm
    Hole diameter300mm
    Final hole diameter75mm
    Drill rodΦ60
    Drilling angle90°--65°
    Vertical axis
    Vertical shaft forward speed65-1172 r/min
    Vertical shaft reverse speed51-242 r/min
    Vertical shaft reverse speed560mm
    Vertical shaft lifting capacity6000kg
    Main winch
    Single rope lifting speed0.5-1.9m/s
    Wire rope diameter12.5mm
    Single rope lifting capacity3000kg
    Roll diameter300mm
    Roll capacity50m
    Gear pump
    Gear oil pumpCBF-F63/25
    Front flow pressure63L/min 20Mpa
    After flow pressure25L/min 20Mpa
    Rig power
    Diesel engine33KW
    Motor22KW
    Weight&Size
    Rig weight1480KG
    Dimensions2500*900*1800mm

    Note: The product is continuously improved, and subject to change without notice, please refer to the actual product.
