Tungsten Carbide Bits for Geological Drilling Tools

Ask Lasest Price
Brand Name :	Aoxing
Model Number :	AQ、BQ、NQ、HQ、PQ、PQ3、HQ3、NQ3、BQ3、NQ2
Certification :	ISO9001
Supply Ability :	500Sets/Month

Add to Cart

Product Details
Company Profile

Tungsten Carbide Bits for Geological Drilling Tools

Tungsten Carbide Bits for Geological Drilling Tools

Brief Introductions of Tungsten Carbide Bits
The tungsten carbide bits use tungsten carbide as the cutting media. The crown of tungsten carbide bits are embedded with rectangular-shaped or octagonal-shaped tungsten-carbide elements. This bit is similar to impregnated diamond core bits in which the bit crown is composed of several layers of cutting media. New layers of carbide-chips will be exposed after the former one is worn away, until the bit crown is consumed.

Features of Tungsten Carbide Bits
1) The bit crown of tungsten carbide bits adopts a tough, wear resistant metal matrix material.
2) Has a wider range of application in various formations owing to more cutting edges.

This diamond tool is widely applied in geotechnical soil investigation or for core drilling in overburden layers (composed of clay, sand, gypsum or soft shale).

Size:

Q Series Bit

No.	Std.	Item	OD*ID(mm)	Crown Height	SN.
1	AQ	diamond bit	47.6*27.0	C9	K3 K5 K7 K9
2	BQ-0.5	diamond bit	59.0*36.3	C9 C12	K3 K5 K7 K9
3	BQ	diamond bit	59.5*36.3	C9 C12	K1-K11
4	NQ	diamond bit	75.3*47.6	C9 C12	K1-K11
5	NQ+2	diamond bit	77.3*47.6	C9 C12	K3 K5 K7 K9
6	HQ	diamond bit	95.6*63.5	C9 C12	K1-K11
7	HQ+2	diamond bit	98.0*63.5	C9 C12	K3 K5 K7 K9
8	PQ	diamond bit	122.0*85.0	C9 C12	K1-K11
9	SQ	diamond bit	147.6*102.0	C9	K3 K5 K7 K9
10	NQTT	diamond bit	75.3*45.0	C9 C12	K3 K5 K7 K9
11	HQTT	diamond bit	95.6*61.1	C9 C12	K3 K5 K7 K9
12	PQTT	diamond bit	122.0*83.0	C9 C12	K3 K5 K7 K9
13	NQ2	diamond bit	75.3*50.7	C9 C12	K3 K5 K7 K9

TW/QV Series Bit

No.	Std.	Item	OD*ID(mm)	Crown Height	SN.
TW Series
1	ATW	diamond bit	47.6*30.1	C9	K3 K5 K7 K9
2	BTW	diamond bit	59.5*42.0	C9	K3 K5 K7 K9
3	NTW	diamond bit	75.3*56.1	C9	K3 K5 K7 K9
QV Series
1	NQV	diamond bit	76.3*50.7	C9 C12	K3 K5 K7 K9
2	HQV	diamond bit	95.0*68.5	C9 C12	K3 K5 K7 K9

JS/XJS系列钻头

No.	Std.	Item	OD*ID(mm)	Crown Height	SN.
JS Series
1	JS76	diamond bit	75.3*49.0	C9 C12	K1-K11
2	JS95	diamond bit	95.0*63.0	C9 C12	K1-K11
XJS Series
1	XJS56	diamond bit	57.3*35.0	C9 C12	K1-K11
2	XJS75	diamond bit	77.3*46.0	C9 C12	K1-K11
3	XJS122	diamond bit	122.0*80.5	C9 C12	K3 K5 K7 K9

CHD Series Bit

No.	Std.	Item	OD*ID(mm)	Crown Height	SN.
1	CHD76	diamond bit	77.3*44.5	C9 C12	K3 K5 K7 K9
2	CHD98	diamond bit	98.0*62.0	C9 C12	K3 K5 K7 K9

Q3 Series Bit

No.	Std.	Item	OD*ID(mm)	Crown Height	SN.
1	BQ3	diamond bit	59.5*33.5	C9 C12	K3 K5 K7 K9
2	NQ3	diamond bit	75.3*45.0	C9 C12	K3 K5 K7 K9
3	HQ3	diamond bit	95.6*61.1	C9 C12	K3 K5 K7 K9
4	PQ3	diamond bit	122.0*83.0	C9 C12	K3 K5 K7 K9
5	SQ3	diamond bit	147.6*102.0	C9	K3 K5 K7 K9

C6 C9	K3 K5 K7 K9
8	T6-86	diamond bit	86.0*67.0	C6 C9	K3 K5 K7 K9
9	T6-101	diamond bit	101.0*79.0	C6 C9	K3 K5 K7 K9
10	T6-116	diamond bit	116.0*93.0	C6 C9	K3 K5 K7 K9
11	T6-131	diamond bit	131.0*108.0	C6 C9	K3 K5 K7 K9
12	T6-146	diamond bit	146.0*123.0	C6 C9	K3 K5 K7 K9
13	T6S-76	diamond bit	76.3*47.7	C6 C9	K3 K5 K7 K9
14*	T6S-86	diamond bit	86.3*57.7	C6 C9	K3 K5 K7 K9
15	T6S-101	diamond bit	101.3*71.7	C6 C9	K3 K5 K7 K9
16	T6S-116	diamond bit	116.3*85.7	C6 C9	K3 K5 K7 K9
17	T6S-131	diamond bit	131.3*100.7	C6 C9	K3 K5 K7 K9
18	T36	diamond bit	36.0*21.7	C6	K3 K5 K7 K9
19	TT46	diamond bit	46.0*35.2	C6	K3 K5 K7 K9
20	TT56	diamond bit	56.0*45.2	C6	K3 K5 K7 K9

MLC/WG/WM Bit

No.	Std.	Item	OD*ID(mm)	Crown Height	SN.
1	NMLC	diamond bit	75.3*52.0	C6 C9 C12	K3 K5 K7 K9
2	HMLC	diamond bit	98.8*63.5	C6 C9 C12	K3 K5 K7 K9
1	AWG	diamond bit	47.6*30.1	C6 C9	K3 K5 K7 K9
2	BWG	diamond bit	59.5*42.0	C6 C9	K3 K5 K7 K9
3	NWG	diamond bit	75.3*54.7	C6 C9	K3 K5 K7 K9
4	NWM	diamond bit	75.3*54.7	C6 C9	K3 K5 K7 K9

JP/YP Bit

No.	Std.	Item	OD*ID(mm)	Crown Height	SN.
1	YP36	diamond bit	36.5*21.5	C6 C9	K3 K5 K7 K9
2	YP47	diamond bit	46.5*29.5	C6 C9	K3 K5 K7 K9
3	JP75	diamond bit	75.3*54.5	C6 C9	K3 K5 K7 K9
4	JP95	diamond bit	95.0*63.0	C6 C9	K3 K5 K7 K9
5	JP110	diamond bit	111.0*79.0	C6 C9	K3 K5 K7 K9
6	JP130	diamond bit	131.0*94.0	C6 C9	K3 K5 K7 K9

Tungsten Carbide Bits for Geological Drilling Tools
