Geological Exploration Core Drilling Casing Shoe Pw Hw Nw Rod Shoe

Ask Lasest Price
Brand Name :	Aoxing
Model Number :	AW, BW, NW, HW, HWT, PW
Certification :	ISO9001

Add to Cart

Product Details
Company Profile

Geological Exploration Core Drilling Casing Shoe Pw Hw Nw Rod Shoe

Geological Exploration Core Drilling Casing Shoe Pw Hw Nw Rod Shoe

Product Description

In the drilling and rock coring industry, a casing shoe is an essential tool used in conjunction with a casing string. Here are the characteristics, usage, features, principle description, and requirements of a casing shoe:
Characteristics:

Design: A casing shoe is typically a specialized fitting attached to the bottom end of a casing string. It is designed to facilitate the drilling and casing process by providing a durable and reliable connection between the casing and the rock formation.
Material: Casing shoes are commonly made of durable materials such as hardened steel or tungsten carbide to withstand the rigors of drilling and to provide efficient cutting and wear resistance.
Cutting Structure: Casing shoes feature a cutting structure, such as carbide or diamond-impregnated cutting elements, that helps penetrate and drill through the rock formation during casing advancement.

Rod&Casing Bit

W Series Casing Bit

No.	Std.	Item	ODID(mm)内径(mm)	Crown Height	SN.
1	AW	casing bit	59.5*45.2	C6	K3
2	BW	casing bit	75.3*56.3	C6	K3
3	NW	casing bit	91.8*72.1	C6	K3
4	HW	casing bit	117.6*95.9	C6	K3
5	PW	casing bit	143.5*117.6	C6	K3
6	SW	casing bit	172.5*143.0	C6	K3

X Series Casing Bit

No.	Std.	Item	ODID(mm)内径(mm)	Crown Height	SN.
1	AX	casing bit	59.5*45.2	C6	K3
2	BX	casing bit	75.3*56.3	C6	K3
3	NX	casing bit	91.8*72.1	C6	K3
4	HX	casing bit	117.6*95.9	C6	K3
5	PX	casing bit	143.5*117.6	C6	K3
6	SX	casing bit	172.5*143.0	C6	K3

Geological Exploration Core Drilling Casing Shoe Pw Hw Nw Rod Shoe
